Estimating the effect of one variable on another is at the core of causal inference. However, doing this with observational data can be challenging, particularly when confounding variables are present.
The Backdoor Criterion, introduced by Judea Pearl, provides a systematic way to identify which variables you should control for to estimate a causal effect accurately.
In the following article, we will explain the Backdoor Criterion using real-life examples. We will simulate data for each of them and estimate the simple causal effect using regression analysis in Python.
DAGs: Drawing the Map of Causality.
To fully understand the backdoor criterion, we must introduce causal diagrams. They are the backbone of Judea Pearl’s causal inference approach, and understanding the general concept is relatively straightforward and intuitive.
A Directed Acyclic Graph (DAG) is a tool for visualising and reasoning about causal relationships between variables. The main components of each graph are nodes and arrows. In a DAG, nodes represent variables and directed edges (arrows) represent causal effects.
The arrows explain the ‘directed’ part. What about acyclic? It’s also quite simple, as it means that the arrows can go only in one direction. There are no feedback loops in DAGs; there is no way to return to the specific node once arrows are going out of it. For now, it may sound abstract, but the examples below will help clarify the applications of graphs in discovering causal effects.
As usual, the reality is much messier, and we will rarely have a straightforward way to estimate the causal effect, especially when working with observational data. In such situations, DAGs are becoming increasingly complex, and estimating causal effects requires conditioning and accounting for other variables.
There are so-called backdoor paths in DAGs, and one way to calculate the causal impact in such situations is to apply the backdoor criterion. – O
The Backdoor Criterion: Systematically Identifying Control Variables
The Backdoor Criterion is a rule that helps to identify which variables to control for when estimating a causal effect from observational data. Let’s start with the formal definition.
A set of variables Z satisfies the Backdoor Criterion relative to a treatment X and an outcome Y if:
1. No variable in Z is a descendant of X and
2. Z blocks every path between X and Y that contains an arrow into X
If these conditions hold, conditioning on Z allows us to estimate the causal effect of X on Y even from observational data. If these criteria are met, we can estimate the treatment effect as if we had data from a randomised experiment.
A backdoor path is any path from X to Y that starts with an arrow pointing into X, representing non-causal associations that could confound the actual causal effect.
This definition is even more abstract than that of DAGs, and I had considerable difficulty understanding the practical implications of these rules. However, this is easier to understand by examining practical examples.
In practice, applying the backdoor criterion means adjusting for common causes (confounders) of both X and Y, while avoiding adjustment for variables affected by X (mediators) or influenced by both X and Y (colliders).
By conditioning on the variable, we will include it as a dependent variable in the linear regression formula.
We will examine each of these situations using linear regression and simulated data in the examples below.
Case 1 (Confounder): Handling Common Causes (The Confounder Bias)
Imagine you’re evaluating whether job training improves employee productivity. However, the job training was not conducted on the randomly selected sample of employees. As a result, all employees were able to take part in the training.
This makes the assessment of this program much more difficult, as many factors can influence both productivity and participation in the training program.
A key problem is that more motivated employees are both more likely to attend training and to perform better, regardless of whether they receive training.
To simplify, we will measure the following three variables, represented in the simulated data below:
motivation = np.random.normal(0, 1, n)
training_hours = 0.9 * motivation + np.random.normal(0, 2, n)
productivity = 5 * training_hours + 3 * motivation + np.random.normal(0, 1, n)
data1 = pd.DataFrame({'motivation': motivation,
'training_hours': training_hours,
'productivity': productivity })
- Employee motivation – regardless of how it’s measured, for example, as a result of employee surveys
- TrainingHours – number of hours an employee spent in the training program
- Productivity
The data is constructed so that motivation affects both training hours and productivity, as shown in the DAG below.
In such a case, motivation acts as a confounder. We also hard-coded the actual effect of motivation on productivity as a 5-unit increase in productivity with each one-unit increase in training hours.
What is a confounder? It is a variable that influences both X and Y, potentially biasing the causal effect. It affects both the treatment and the outcome variable. I
In our case, motivation affects both training hours and productivity. How can we measure the causal effect of the training programs in such a case?
The most straightforward approach is to ignore motivation and focus solely on estimating the effect of training on productivity. We can do it by running a regression with training hours as an independent variable:
## without adjustment
print("Naive regression without adjustment:")
naive_model1 = smf.ols('productivity ~ training_hours', data=data1).fit()
print(naive_model1.summary())
## with adjustment
print("Regression with adjustment for motivation:")
model1 = smf.ols('productivity ~ motivation + training_hours', data=data1).fit()
print(model1.summary())
Unsurprisingly, the results do not accurately reflect the treatment effect. According to this model, each additional hour of training increases productivity by 5.56 units. The treatment effect is 11% higher than the actual effect.
The difference might not be drastic, but it clearly shows that failing to adjust for the confounder (motivation) leads to a biased estimate of the treatment effect.
The effect is higher than the actual because more motivated employees are more productive and more likely to participate in the training program.
According to the Backdoor Criterion, to estimate the causal effect of Training Hours on Productivity, we need to block any backdoor paths from Training Hours to Productivity. The only backdoor path here is:
- TrainingHours <- Motivation -> Productivity
This requires us to control for motivation to isolate the actual effect of training. By conditioning on Motivation, we block this backdoor path.
Motivation is not a descendant of Training Hours and blocks the non-causal path, so the criterion is satisfied according to the definition above. To control for motivation, we will run another regression model that includes motivation as an additional variable.
This time, the treatment effect, represented by the coefficient on the training_hours variable, is much closer to the actual impact. The slight difference comes from including the random noise in the simulation.
By adjusting for the confounder, we were able to estimate the treatment effect accurately. We can solidify our knowledge by exploring a slightly more complex example with confounders.
Case 2 (Confounder): Complex Confounding: Seasonality and Economics
This time, let’s switch to the marketing world. We will examine whether increasing ad spend leads to increased sales. However, isolating the effect of marketing spend on sales is a very complex topic.
Both general economic conditions and seasonal fluctuations can impact sales. After all, customers tend to spend more in periods of economic growth.
Additionally, seasonality can impact sales – for example, we tend to buy more ice cream in the summer, or heating bills are higher during the winter.
Let’s simulate our little scenario with the following code. Sales will be impacted by ad spend. However, both advertising spend and sales will be affected by economic conditions and seasonality, as depicted in the graph below.
The actual effect of ad spend on sales is a 3-unit increase in sales for every one-unit increase in advertisement spend.
seasonality = np.random.normal(0, 1, n)
economy = np.random.normal(0, 1, n)
ad_spend = 0.6 * seasonality + 0.4 * economy + np.random.normal(0, 1, n)
sales = 3.0 * ad_spend + 1.0 * seasonality + 0.5 * economy + np.random.normal(0, 1, n)
data2 = pd.DataFrame({'seasonality': seasonality,
'economy': economy,
'ad_spend': ad_spend,
'sales': sales })
We already know that conditioning only on advertisement spend won’t accurately represent the treatment effect. Let’s confirm this with the following formula:
As expected, the naive approach inflates the actual treatment effect. It could be dangerous, as marketing managers make incorrect budget-allocation decisions, resulting in excessive spending with no benefit.
As we already know, we have to adjust for additional variables to uncover the actual treatment effect. The first step is to identify all backdoor paths that need to be controlled.
In our case, there are two backdoor paths from AdSpend to Sales:
- AdSpend <- Seasonality -> Sales
- AdSpend <- Economy -> Sales
By adjusting for both Seasonality and Economy, we will block both non-causal paths. Neither Seasonality nor Economy variables are descendants of AdSpend, so the adjustment satisfies the Backdoor Criterion.
To isolate the effect of advertising on sales, we will run a new regression model this time adjusting for both Seasonality and Economy:
## Naive (unadjusted) regression
naive_model2 = smf.ols('sales ~ ad_spend', data=data2).fit()
print("Unadjusted model:")
print(naive_model2.summary())
## Adjusted regression
model2 = smf.ols('sales ~ ad_spend + seasonality + economy', data=data2).fit()
print("\nAdjusted model:")
print(model2.summary())
As shown below, this model accurately identifies the effect of advertisement spend. As in the example above, the slight difference is due to random noise.
This example illustrates a common business pitfall: analysts attribute higher sales to ads when external factors drive both ads and sales. Again, adjusting for confounders helps us to estimate the causal effect correctly.
Case 3 (Mediator): Mediator Bias: Why You Shouldn’t Control for Everything
Now, let’s imagine we are studying the impact of a personalised email campaign on user purchasing behaviour in the e-commerce setting.
After sending the emails, we track a variety of engagement metrics, including click-through rates, time spent on the website, the number of product pages visited, and interactions with recommended products.
These metrics measure the level of attention and interest the user shows to the platform after receiving the email. We also measure the buying behaviour on our website, as the ultimate goal of our campaign was to increase sales of our products.
We have both engagement and sales data, and our goal is to determine whether the email campaign increased sales. The causal situation is represented in the following graph.
The following code will simulate our data. Note that the actual effect of the email is not directly visible in the code below. It’s happening because the purchase is affected by both emails and engagement. Engagement is also affected by emails. Hence, we can distinguish two ways in which email affects spending:
- Direct effect – email campaign -> purchase
- Indirect effect: email campaign -> purchase -> engagement
n = 1000
email = np.random.binomial(1, 0.5, n)
engagement = 0.8 * email + np.random.normal(0, 1, n)
purchase = 1.2 * engagement + 0.5 * email + np.random.normal(0, 1, n)
data3= pd.DataFrame({'email': email,
'engagement': engagement,
'purchase': purchase })
Based on this, we can see that the simulated data is as follows:
- Direct effect: 0.5 units
- Indirect effect: email coeffcient on engament x enagament on purchase = 0.8 x 1.2 = 0.96
- Total effect of email campaign = 0.5 + 0.96 = 1.46
How should we approach measuring the total effect of the campaigns? In the examples above, we simply conditioned on all the available variables. It’s time to check what happens if we run a similar regression, adjusting for both engagement and email campaign.
The coefficient of email in the model adjusted by engagement is 0.5. However, it captures the full effect of our campaign.
As we saw above, not. This regression captures only the direct impact of the treatment, which is lower than the total effect.
Adjusting in this manner may lead to severe business consequences, as we won’t be able to plan future marketing activities accurately.
What is happening here, then? Why didn’t adjusting for all available factors work, and did it used to work before?
It happens because we no longer have confounders. The engagement metric acts as a mediator, and variables in such a scenario require a different approach.
Let’s take a look at the causal path again. It looks like this:
- Email -> Engagement -> Purchase
- But also: Email -> Purchase
It means that engagement is a mediator — it carries part of the campaign’s causal effect. A mediator is a variable that transmits part of the treatment’s impact on the outcome.
In our case, engagement acts as a mediator, as the email campaign directly causes it. The mediator also lies on the causal pathway between the treatment and the outcome.
From a practical perspective, we should never adjust for mediators, as it introduces the so-called mediator bias, which means we don’t capture the entire treatment effect.
Including a mediator as a control variable means that our model estimates the direct effect of the treatment, not the total effect. This leads to an underestimation of the email campaign’s actual impact and violates the backdoor criterion, as the full causal effect is not captured.
Our goal is to assess the campaign’s overall impact on sales and purchases. To do this, it’s enough to run the regression adjusted only for the email variable.
As shown below, the effect of the email campaign in this case is significantly larger and more closely resembles our simulated example (though it’s not identical due to random noise). We were able to estimate the total effect of the email campaign accurately.
Adjusting for mediators is a hazardous practice that is often overlooked. For example, it’s pretty standard to use all available data to estimate the effect of a particular activity. As this case illustrates, it can lead to incorrect results, which may result in wrong decisions.
It also demonstrates that causal thinking is beneficial, as it enables us to determine the effect accurately.
It serves as a reminder that thinking about the proper structure of the problems is just as important as running the actual analysis. Long story short – we can never adjust for mediators.
Case 4 (Collider): Collider Bias: The Danger of Conditioning on an Effect
Our final example will introduce another type of bias and a situation where adjusting for a variable is worse than doing nothing. We will go into the public health realm.
Suppose we are analysing the relationship between compliance with a public health campaign (e.g., wearing masks or getting vaccinated) and an underlying health risk (e.g., chronic illness).
We will also include doctor visits as another variable in our model. Our goal is to estimate the effect of compliance on the risk of chronic illness.
The causal situation looks like this:
The data are simulated as follows. Both compliance and health risks lead to doctor visits. However, please note that there is no causal path between compliance and risk.
n = 1000
compliance = np.random.binomial(1, 0.5, n)
risk = np.random.normal(0, 1, n)
doctor_visit = 0.8 * compliance + 0.8 * risk + np.random.normal(0, 1, n)
data4= pd.DataFrame({ "compliance": compliance,
"risk": risk,
"doctor_visit": doctor_visit })
Now, let’s suppose we don’t account for the causal graph and include the doctor’s visit variable in our analysis. After all, why not use all the available data?
Using this approach, the doctor’s visit affects the health status. And this effect is quite significant.
Why does the inclusion of the supposedly unrelated variable lead to significant effects? It happens because the doctor’s visit acts as a collider. This is the last type of causal connection we’ll introduce in this article.
A collider is a variable that is causally influenced by two or more variables in a causal graph. As shown above, the arrows from two variables intersect at the doctor’s visit. Collider is an opposition of the confounder – it’s not causing other variables, but is caused by them.
When we condition on the collider as we did in the regression formula, we technically open a non-causal path between variables in our model. This creates a spurious effect that does not exist in reality. We call it a collider bias.
When two variables are truly independent in reality, conditioning on the collider, their common cause, creates a spurious connection between them that does not reflect the actual causal relationship.
Including the doctors’ visit variable in our analysis created a collider bias, as we ‘discovered’ an effect that is not causal. Compliance with health guidelines and risk of diseases are unrelated in the general population. But they become connected when we condition on doctor visits.
It happens because people who visit a doctor are generally at higher risk of disease. After all, relatively few healthy people want to see a doctor. On the other hand, people who are more compliant with public health measures are also more likely to visit a doctor, as they are concerned about preventing various diseases.
When we condition on visiting the doctor, we have two separate groups of people:
- Compliant with public health but without any diseases
- Sick people who are not compliant
Why would they visit a doctor?
If someone is compliant and visits the doctor frequently, they likely have a low risk (because their visits are for preventive care, not illness).
If someone is non-compliant but visits the doctor a lot, it’s probably because they’re sick and have a higher risk of chronic diseases.
Within the group visiting a doctor, compliance and risk of illness become negatively correlated.
How to fix this error? The best approach is to do nothing, as including the doctor’s visit can lead to incorrect results. Let’s see what happens if we run a regression model without doctors – we try to predict the risk of disease by using only the compliance variable.
## Incorrect model (adjusts for collider):
naive_model4 = smf.ols('risk ~ compliance + doctor_visit',data=data4).fit()
print(naive_model4.summary())
## Correct model (does not adjust for collider and there's close to no association between compliance and risk):
model4 = smf.ols('risk ~ compliance', data=data4).fit()
print(model4.summary())
And this time our results are correct – the compliance coefficient is minimal with a large p-value. Compliance does not affect disease incidence, as our simulated data show.
This example shows again that sometimes using too much data is worse than not using it at all. Conditioning on a collider can be very dangerous, as it may lead to incorrect conclusions that, in turn, can result in misguided decisions.
That’s why it’s essential to think about the structure of the data and potential relations between variables before adding them to our model. Only this approach will help us to discover the actual causal effect.
From Theory to Practice: A Summary of Adjustment Rules
Estimating causal effects with observational data is one of the most challenging tasks in analytics. Still, tools like DAGs and the Backdoor Criterion allow us to do it correctly.
In this article, we unpack how causal diagrams reveal pathways that can bias our
estimates, and how to block them by choosing which variables to adjust for in a regression model.
Let’s summarise what we have to do when we encounter the three main types of causal connections:
- Confounder – always block/add to the model
- Mediator – never block/do not add to the model
- Collider – never block/do not add to the model
We had one huge advantage – we already knew what the actual causal relationship between variables looked like. This is not a luxury that any analyst has. This is one of the largest drawbacks associated with causal inference using DAGs.
We rarely know the actual causal diagram; we have to assume certain relationships based on our knowledge and experience.
There are many ways to approach this, which we will cover in the future, ranging from critical domain expertise and discussions with domain experts to the most advanced causal discovery techniques. There are also special tools and libraries to estimate the strength of our assumption, which might help us test it.
However, this drawback is something we must live with. And I have to highlight again – all analytics is about making certain assumptions. Before applying any causal model, even a simple regression, we must carefully consider what we want to discover and which variables make sense. And causal diagrams are the perfect tool for it.
References
Judea Pearl, Causal Inference in Statistics: A Primer, 2016
Pearl, J., & Mackenzie, D. (2018). The Book of Why: The New Science of Cause and Effect. Basic Books.
